Product Feature
Contact Position Indication Function
Maximum Wiring Capacity 25mm²
Overload, short circuit, isolation; Suitable for communication, photovoltaic and other DC system applications.
Advanced Protection: Safeguards against overloads and short circuits, ensuring system reliability in demanding DC applications.
Contact Position Indication: Easily monitor the breaker’s status for enhanced operational safety.
High Wiring Capacity: Supports up to 25 mm² wiring, providing flexibility for various installations.
Versatile Voltage Rating: Rated at 1000VDC for 4-pole configurations, ideal for high-voltage DC systems.
Durable Design: Boasts a mechanical life of 20,000 cycles, ensuring long-term reliability.
Temperature Compensation: Adapts to ambient temperatures from -20°C to 60°C with precise current correction factors for consistent performance.
When the ambient temperature is not the baseline temperature of 30℃，the reference correction coefficient is as follows：
| Ambient Temperature | -20℃ | -10℃ | 0℃ | 10℃ | 20℃ | 30℃ | 40℃ | 50℃ | 60℃ |
| Current Correction Factor | 1.25 | 1.2 | 1.15 | 1.10 | 1.05 | 1.00 | 0.95 | 0.90 | 0.85 |
